| Division | TAIYO Division | Screw Tolerance | JIS 6g/6H |
| Fluid Type | Air | Speed Range | 50-700mm/s |
| Proof Pressure (MPa) | 1.5 | Type | Double Acting Single Rod, Non Rotating Rod, Val set |
| Lubrication | Unnecessary | Related Parts | TA,TC bracket(φ25-40) |
| Mounting Style | Basic style/SD,LC,FA,TA,TC,AD,BD | Cushioning Type | With cushion pads(φ25-40), With cushions on both ends(Semi-standard, φ40) |
| Bellows Material | Nylon tarpaulin | Bore Diameter (mm) | 25, 40 |
| Pressure Range (MPa) | 0.15-1 | Rod End Thread Type | Rod eye(S-end)with spherical bearing,Rod clevis(Y-end)with pin,Floating joint(φ25-40)(F-end:Do not use together with Mounting style TA accessories.) |
| Temperature Range (C) | -10 to +50℃(No freezing) | Allowable Rotational Torque (N・m) | 0.49(φ25), 0.98(φ40) |
| Rotaton Angle Tolerance (degrees) | ±1.5(φ25), ±1(φ40) | | |
