| Division | TAIYO Division | Fluid Type | Petroleum based fluid |
| Speed Range | 8-300mm/s | Related Parts | CD,TA,TC：bracket |
| Mounting Style | SD, LB, FA, FB, CA, CC, CB, CD, TA, TC | Proof Pressure | 1.5 |
| Rod End Styles | Rod eye(T-end),Rod eye(S-end),Rod clevis(Y-end)with pin, Floating joint | Cushioning Type | None Use the piston contact speed 50mm/s or less with end cover. |
| Screw Tolerance | JIS 6g/6H | Bellows Material | Nylon tarpaulin(Standard), Chloroprene(Semi-standard),Conex(Semi-standard) |
| Bore Diameter (mm) | 32, 40, 50, 63, 80, 100, 125, 140, 160, 180, 200, 250 | Temperature Range (C) | -10-+80(No freezing) |
| Stroke Length Tolerance (mm) | 0-+1.0(0-250mm), 0-+1.4(251-1000mm), 0-+1.8(1001-2000mm) | Maximum Working Pressure (MPa) | 1 |
| Minimum Operating Pressure (MPa) | 0.1 | | |
