Picture of Parker 30GH-12 - Plastic Barbed Fittings, Parker Par-Barbs

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 30GH-12 - Plastic Barbed Fittings, Parker Par-Barbs

Parker's Par-Barb fttings are specially engineered with a four-barb design that generates maximum gripping and sealing power when combined with a hose clamp.
Availability:
55 In Stock
Richmond, VA40
Knoxville, TN9
Knoxville, TN5
Partner Available:383 In Stock
Brand Parker
Part No. 30GH-12
TBD
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
UOMEADivisionFluid System Connectors Division
Minimum Operating Temperature-40 °FMediaWater, Air, Other Compatible Fluids
Specifications MetFDA, NSF-51Maximum Operating Temperature200 °F
Maximum Operating Pressure8.5 barDimensional Weight0.5755 lb
ApplicationChemical Dispensing, Pneumatic Systems, Food Processing, Beverage DispensingTube MaterialVinyl, Polyurethane, Rubber Hose
DivisionFluid System Connectors DivisionConnection 1 Size3/4
Connection 2 Sizen/aVacuum Pressure Rating-29
Body MaterialPolypropyleneConnection 1 TypeGarden Hose
TechnologyFluid & Gas HandlingColorWhite
Connection 3 SizeN/ABrandParker
ShapeWasherCompatible TubeVinyl
Connection 3 TypeN/AConnection 2 Typen/a
ConfigurationPipe to PipeConnection 2 Hose I.D. (inch)n/a
Body MaterialNylon,WhiteConnection 1 Thread Size3/4"
Connection 1 Hose I.D. (inch)n/aProduct StyleGarden Hose Thread
Connection 1 TypeFemale Garden HoseConnection 3 TypeN/A
ColorWhiteShapeWasher
Connection 2 SizeN/AConnection 2 TypeN/A
ConfigurationPipe to PipeConnection 1 Size3/4"
Connection 3 SizeN/A
