| Division | TAIYO Division | Fluid Type | Petroleum-based fluid(When using another fluid,give us such instructions.) |
| Screw Tolerance | JIS 6g/6H | Proof Pressure (MPa) | 15 |
| Temperature Range (C) | -10-+80 (Ambient temperature, No freezing) | Nominal Pressure (MPa) | 10 |
| Seal Material | 1:Nitrile rubber 6:HNBR | Type | Double Acting Single Rod, Standard type |
| Speed Range | 8-500mm/s(excluding cushion), 8-100mm/s(Without cushion) | Rod End Type | Rod eye(T-end),Rod clevis(Y-end)with pin,Floating joint(F-end:Do not use together with Mounting style CA accessories.) |
| Body Material | Carbon steel for machine structural use | Mounting Style | SD,LB,FA,CA |
| Cushioning Type | Metal fitting system (floating cushion) | Bore Diameter (mm) | 20, 25, 32 |
| Stroke Length Tolerance (mm) | 0-+0.8(0-100mm), 0-+1.0(101-250mm), 0-+1.25(251-500mm), 0-+1.4(501-850mm) | Maximum Working Pressure (MPa) | 12 |
| Minimum Operating Pressure (MPa) | 0.3 | | |
