Parker 003-0165-900 - Series 3 – Miniature Inert Liquid Valve

Parker's Series 3 family of liquid valves provide an inert wetted path for your aggressive liquids including bleach and other harsh solvents.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 003-0165-900

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Division	Precision Fluidics Division	Weight	2.7 oz
Shipping Weight	0.35	Max Order Quantity	9
Standard Lead Time	20	Out of Stock Lead Time	40
Width	1.0 inch	Height	53.34 mm
Length	1.0 inch	Function	3-Way
Flow Rate	up to 1500 cm3/min	Leak Rate	Bubble Tight
Orifice Size	1.98 mm	Body Material	PEEK
Configuration	n/a	Input Voltage	24 VDC
Mounting Type	Mounting Screw	Seal Material	FKM
Actuation Type	Solenoid	Control Method	Current or Voltage
For Fluid Type	Liquids (Bleach Compatible)	Operation Type	Electronic
Connection Size	1/8 inch	Connection Type	Barb for I.D. Tubing
Maximum Flow Rate	1500 cm3/min	Power Consumption	4.2 W
Cycles per Lifetime	10 Million	Industry Application	Highly aggressive media dispensing and control
Electrical Connection	12" Wire Leads	Vacuum to Pressure Range	Vacuum to 50 Psig (3.44 bar)
Maximum Operating Pressure	50 psi	Maximum Operating Temperature	150 °F
Minimum Operating Temperature	40 °F	Voltage (VDC)	24
Valve Configuration Type	3 Way Universal	Orifice Size	0.078"
Fluid Compatibility	Without Bleach	Physical Connection	1/8" Barbs
Chemical Resistance Required	High - PEEK Body, FKM Diaphragm
