797TC Series

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker’s GlobalCore 797ST hose provides 6,000 psi (35 MPa) constant working pressure in all sizes. ½ bend radius of SAE spiral hose. Flex impulse tested providing a hose superior in both performance and service life. Meets ISO 18752 performance specification.

View as Grid List

Sort by

Display per page

Part No.	Availability	Partner Available	Price	UOM	Inner Diameter	Material	Mating Fitting Series	Working Pressure	Parker Group	Inch/Metric	Parker Division	Inner Diameter	Inner Diameter Inch/mm	Material	Application	Working Pressure Range	Hose Category	Trade Name	Mating End Fitting Series	Specification	Operating Temperature	Hose Pressure Range	ISO 18752 Performance	Series	Distinct Properties	Working Pressure	Minimum Bend Radius
797TC-10-RL	623 In Stock	1911 In Stock	$32.82/foot	FT	0.625 Inch	Rubber	77	6,000 psi (42 MPa)	Fluid Connector	Inch	Hose Products	0.625 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	GlobalCore	77	ISO 18752	-40°F to +257°F (-40°C to +125°C)	High	DC	797TC	Tough Cover Constant Pressure 6000 PSI	6,000 psi (42 MPa)	4 1/2 Inch
797TC-12-RL	2007 In Stock	8854 In Stock	$46.65/foot	FT	0.75 Inch	Rubber	77	6,000 psi (42 MPa)	Fluid Connector	Inch	Hose Products	0.75 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	GlobalCore	77	ISO 18752	-40°F to +257°F (-40°C to +125°C)	High	DC	797TC	Tough Cover Constant Pressure 6000 PSI	6,000 psi (42 MPa)	5 1/4 Inch
797TC-16-RL	1681 In Stock	5060 In Stock	$57.35/foot	FT	1 Inch	Rubber	77	6,000 psi (42 MPa)	Fluid Connector	Inch	Hose Products	1 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	GlobalCore	77	ISO 18752	-40°F to +257°F (-40°C to +125°C)	High	DC	797TC	Tough Cover Constant Pressure 6000 PSI	6,000 psi (42 MPa)	6 1/2 Inch
797TC-32-BX	Quote Required	50 In Stock	$179.60/foot	FT	2 Inch	Rubber	77	6,000 psi (42 MPa)	Fluid Connector	Inch	Hose Products	2 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	GlobalCore	77	ISO 18752	-40°F to +257°F (-40°C to +125°C)	High	DC	797TC	Tough Cover Constant Pressure 6000 PSI	6,000 psi (42 MPa)	15 Inch
797TC-4-BX	Quote Required	30 In Stock	$8.04/foot	FT	0.25 Inch	Rubber	43	6,000 psi (42 MPa)	Fluid Connector	Inch	Hose Products	0.25 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	GlobalCore	43	ISO 18752	-40°F to +212°F (-40°C to +100°C)	High	AC	797TC	Tough Cover Constant Pressure 6000 PSI	6,000 psi (42 MPa)	2 Inch
797TC-4-RL	510 In Stock	26840 In Stock	$6.49/foot	FT	0.25 Inch	Rubber	43	6,000 psi (42 MPa)	Fluid Connector	Inch	Hose Products	0.25 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	GlobalCore	43	ISO 18752	-40°F to +212°F (-40°C to +100°C)	High	AC	797TC	Tough Cover Constant Pressure 6000 PSI	6,000 psi (42 MPa)	2 Inch
797TC-6-RL	942 In Stock	5871 In Stock	$18.04/foot	FT	0.375 Inch	Rubber	43	6,000 psi (42 MPa)	Fluid Connector	Inch	Hose Products	0.375 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	GlobalCore	43	ISO 18752	-40°F to +212°F (-40°C to +100°C)	High	CC	797TC	Tough Cover Constant Pressure 6000 PSI	6,000 psi (42 MPa)	2 1/2 Inch
797TC-8-RL	1145 In Stock	6977 In Stock	$30.05/foot	FT	0.5 Inch	Rubber	43	6,000 psi (42 MPa)	Fluid Connector	Inch	Hose Products	0.5 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	GlobalCore	43	ISO 18752	-40°F to +257°F (-40°C to +125°C)	High	DC	797TC	Tough Cover Constant Pressure 6000 PSI	6,000 psi (42 MPa)	4 Inch
