Switches, Gauges and Indicators
*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.
Parker’s Hydraulic and Fuel Filtration Division offers a broad range of gauges, switches, and indicators across multiple filter product series. Differential pressure increases as a hydraulic filter element captures harmful contamination from system fluid. Filter elements must be replaced once the specified differential pressure is reached. Parker’s indicators signal when a filter element must be replaced to ensure system cleanliness and protect system critical assets.
Indicator Types: Pressure Gauge, Vacuum Gauge, Pressure Switch, Visual, Electrical/Visual, Electrical Reed Switch, Analog 4-20mA
Applicable Filter Series: 12AT, 50AT, 80AT, 80UT, Moduflow Plus ILP DILP, PT, GLF, BGT17, 15P, 30P, 50P, WPF
Read More...Indicator Types: Pressure Gauge, Vacuum Gauge, Pressure Switch, Visual, Electrical/Visual, Electrical Reed Switch, Analog 4-20mA
Applicable Filter Series: 12AT, 50AT, 80AT, 80UT, Moduflow Plus ILP DILP, PT, GLF, BGT17, 15P, 30P, 50P, WPF
| Action | Part No. | Availability | Partner Available | Price | UOM | Division | Product Series | Product Type | Maximum Operating Temperature | Seal Material | Signal Output | Indicator Pressure Setting | Maximum Operating Pressure |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 925337 | Quote Required | $220.85/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | 50P | Indicator Repair Kit | 135.0 °C | N/A | Electrical Switch repair kit | 50 psid (3.45 bar) | N/A | ||
| 926643 | Quote Required | 3 In Stock | $274.73/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | Moduflow Plus ILP, DILP | Differential Pressure Indicator Assembly | 135.0 °C | Fluorocarbon | Electrical | 35 psid (2.4 bar) | 200 psi (13 bar) | |
| 926748 | Quote Required | 24 In Stock | $178.37/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | Moduflow Plus ILP, DILP | Differential Pressure Indicator | 135.0 °C | Fluorocarbon | Visual 4 Band | 35 psid (2.4 bar) | 200 psi (13 bar) | |
| 926753 | Quote Required | 4 In Stock | $301.25/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | Moduflow Plus ILP, DILP | Differential Pressure Indicator | 275.0 °F | Fluorocarbon | Electrical with 3-pin male quick disconnect | 35 psid (2.4 bar) | 200 psi (13 bar) | |
| 926923 | Quote Required | 21 In Stock | $99.70/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | PT, 12AT, 50AT, 80AT, 80UT | Pressure Switch | 225.0 °F | N/A | Electrical | 24 psi (1.65 bar) | 150 psi (10.3 bar) | |
| 929587 | 5 In Stock | Quote Required | $204.75/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | 15P, 30P, CN, MPD | Differential Pressure Indicator | 275.0 °F | Fluorocarbon | Electrical/Visual with flying leads | 50 psid (3.45 bar) | 3000 psi (207 bar) | |
| 929596 | Quote Required | 18 In Stock | $329.53/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | 15P, 30P, CN, MPD | Differential Pressure Indicator | 275.0 °F | Fluorocarbon | Electrical/Visual with 3-pin ANSI/B93.55M | 50 psid (3.45 bar) | 3000 psi (207 bar) | |
| 929599 | Quote Required | 21 In Stock | $240.67/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | 15P, 30P, CN, MPD | Differential Pressure Indicator | 275.0 °F | Fluorocarbon | Electrical/Visual wih DIN 43650 | 50 psid (3.45 bar) | 3000 psi (207 bar) | |
| 932027 | Quote Required | 139 In Stock | $92.20/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | 15P, 30P, IL8, CN, MPD | Differential Pressure Indicator | 135.0 °C | Fluorocarbon | Visual | 50 psid (3.45 bar) | 3000 psi (207 bar) | |
| 936909 | Quote Required | 18 In Stock | $48.67/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | 12AT, 50AT, 80AT, 80UT | Vacuum Gauge | 225.0 °F | N/A | Visual Tri-Color | 6 inHg (0.2bar) | 150 psi (10.3 bar) | |
| 936911 | Quote Required | 10 In Stock | $49.38/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | 12AT, 50AT, 80AT, 80UT | Pressure Gauge | 225.0 °F | N/A | Visual Tri-Color | 12 psi (0.83 bar) | 150 psi (10.3 bar) | |
| 936912 | 19 In Stock | 121 In Stock | $48.86/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | PT, 12AT, 50AT, 80AT, 80UT | Pressure Gauge | 107.0 °C | N/A | Visual Tri-Color | 22 psi (1.5 bar) | 150 psi (10.3 bar) | |
| 945661 | Quote Required | 42 In Stock | $208.95/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | WPF | Differential Pressure Indicator | 250.0 °F | Fluorocarbon | Visual | 50 psid (3.45 bar) | 7000 psi (483 bar) | |
| 946201 | Quote Required | 5 In Stock | $287.71/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | WPF | Differential Pressure Indicator | 250.0 °F | Fluorocarbon | Electrical Reed Switch | 50 psid (3.45 bar) | 7000 psi (483 bar) | |
| 946326 | Quote Required | 86 In Stock | $22.44/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | GLF | Pressure Gauge | 135.0 °C | N/A | Visual Tri-Color | 30 psi (2.07 bar) | 150 psi (10.3 bar) | |
| 947355 | Quote Required | 5 In Stock | $65.40/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | WPF | DIN 43650 LED Indicator Socket | 250.0 °F | Synthetic Rubber Gasket | LED Visual | N/A | N/A | |
| 947356 | Quote Required | 11 In Stock | $23.87/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | WPF | DIN 43650 Indicator Socket | 250.0 °F | Synthetic Rubber Gasket | Electrical Socket | N/A | N/A | |
| FF3468 | Quote Required | $1,336.44/each | EA | Engine Mobile Hydraulic and Fuel Filtration Division | BGT17 | Differential Pressure Indicator | 120.0 °C | Fluorocarbon | Electrical Actuator with DIN 43650-A | 18 psid (1.2 bar) | 150 psi (10.3 bar) |
