Parker WSPX025DGFX - OIL-X Grade WS Compressed Air Water Separator (For Pressures Up To 16 barg)

Die cast aluminium water separators for the efficient removal of bulk liquid contamination from a compressed air supply, providing flow rates up to 3600 m³/h @ 7 bar g.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. WSPX025DGFX

$895.86

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Product Series	OIL-X Grade WS
Product Type	Compressed Air Filter	Industry	Industrial Manufacturing Equipment<br/> Food & Beverage<br/> Automotive<br/> Electronics<br/> Pharmaceuticals<br/> Medical & Dental
Height	277.0 mm	Division	Gas Separation and Filtration Division EMEA
Technology	Filtration	Pressure Differential	1.4 psi Initial Saturated, 100% Flow
Micron Rating	n/a	Specifications Met	Fully tested - In accordance with ISO12500-4 & ISO8573-9 for liquid water. <br/><br/>Separation performance independently validated - by Lloyds Register.<br/><br/>PED 2014/68/EU Fluid Group II
Application	Compressed Air and Nitrogen Gas Applications	Operating Pressure	22 to 232 psig
Width	120.0 mm	Brand	Parker
Filter Type	Water Separator	Operating Temperature	35 to 149 °F
Weight	2.66 kg	Division	Gas Separation and Filtration Division EMEA
Materials of Construction	Die Cast Aluminium	Depth	4.53 inch
Maximum Flow Rate	396 m³/h @ 7 barg (233 cfm @ 102 psig)	Electrical Requirements	N/A
Connection Type	BSPP	Drain Option	Automatic Float
Port Size	¾ inch	Drain	Float
Compatible Element	N/A
