Parker T5-1HE-03-1EEB - T2-05 Micro Diaphragm Pump

Parker's T2-05 micro diaphragm pump is designed to fit where other pumps cannot due to its small, compact package size. The pump's low power, small size, and light weight play a critical role in portable gas detection and medical applications.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. T5-1HE-03-1EEB

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Body Material	ABS	Flow Rate	0.8 L/min
For Fluid Type	Air	Product Type	Diaphragm Pump
Industry Application	Sidestream CO2	Operational Life	10000 Hours
Operating Pressure	6.2 psi	Motor Type	Coreless Brush (High Efficiency)
Length	32.6 mm	Weight	14 g
Maximum Continuous Pressure	2.0 psi	Maximum Continuous Vacuum Pressure	-104 mm-Hg
Height	0.89 inch	Vacuum Pressure Rating	-274 mm-Hg
Noise Level	45 dBA	Width	0.53 inch
Division	Precision Fluidics Division	Operating Temperature	-20 to 50 °C
Diaphragm Material	EPDM	Operational Life	Up to 10,000 Hours
Pump Type	Pressure and/or Vacuum	Motor Option	Coreless Brush (High Efficiency)
Free Flow Rate	Up to 0.8 L/min	Pump Size	Single Head
