| UOM | EA | UOM | EA |
| Pkg Qty/UOM | 1 EA | Pkg Qty | 1 |
| Body Material | Steel | Adjustment Type | Screw |
| Port | 8 SAE | Operating Temperature | -45C to +93.3C (-50F to +200F) |
| Seals | “D”-Ring | Max Pressure | 380 Bar (5500 PSI) |
| Rated Flow | 56.3 LPM (15 GPM) | Pressure Range | 6.9 - 69 Bar (100 - 1000 PSI) |
| Leakage | 82 cc/min. (5 cu. in./min.) @ 210 Bar (3000 PSI) | Parker Group | Hydraulic |
| Parker Division | Hydraulic Cartridge Systems | Body Material | Steel |
| Adjustment Type | Screw | Operating Temperature | -45C to +93.3C (-50F to +200F) |
| Port | 8 SAE | Seals | “D”-Ring |
| Max Pressure | 380 Bar (5500 PSI) | Rated Flow | 56.3 LPM (15 GPM) |
| Series | SVCH101 | Valve Type | Sequence Valve |
| Pressure Range | 6.9 - 69 Bar (100 - 1000 PSI) | Valve Type Detail | Pilot Operated - Internal with Check |
| Leakage | 82 cc/min. (5 cu. in./min.) @ 210 Bar (3000 PSI) | | |
