Parker SST-1MY - High Flow, Unvalved, Hydraulic Quick Couplings - ST Series

Parker's high flow quick couplers and nipples are unvalved for use where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. SST-1MY

$82.68/each

Products specifications

Attribute name	Attribute value
UOM	EA	Body Material	Stainless Steel
Hex Size	0.56 inch	Flow Rate	3 Gal/min
Minimum Operating Temperature	-15 °F	Application	High Flow
Product Type	Push to Connect	Seal Material	Fluorocarbon
Maximum Operating Temperature	400 °F	Valve Type	Unvalved
Division	Quick Coupling Division	Connection Type	Male NPTF
Coupling Half	Female Coupler	Body Material	303 Stainless Steel
Maximum Operating Pressure	4200	Connection Thread Size (inch)	1/8 - 27
Body Size (inch)	1/8
