Parker RX24 L3 40 - Transair® Fittings for Aluminum Pipe

Transair Fittings install fast and with minimal tooling required. All Transair fittings are designed to securely fit around Transair aluminum pipe, increasing system efficiency and preventing compressed air leaks.

Availability:	Quote Required
Partner Available:	59 In Stock

Brand Parker

Part No. RX24 L3 40

$206.24

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Assembly Time	0.04 Hours
Body Material	Stainless Steel 304	Brand	Parker
Vacuum Pressure Rating	0.03 inch-Hg	Division	Low Pressure Connectors Europe Division
Application	Compressed Air	Industry	General Industrial
Connection 2 Size	1-1/2 inch	Configuration	Pipe to Pipe
Maximum Operating Temperature	85 °C	Technology	Pneumatics
Product Type	Compressed Air Piping	Maximum Operating Pressure	16 bar 232 PSI (-4°F to +113°F)/16 bar (-20°C to 45°C) up to 100 mm 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/ca
Minimum Operating Temperature	-20 °C	Weight	3.46 lb
Division	Fluid System Connectors Division	Quantity per Box	1
Specifications Met	EN 573.3	Shape	Reducing Tee
For Fluid Type	Industrial Gas	Product Style	Union Fitting
Connection 1 Type	Pipe	Connection 1 Size	4 inch
Connection 2 Type	Pipe	Pipe O.D. 2 (mm)	63
Connection Thread Size (inch)	n/a	Silicone Free	Yes
Product Style	Pipe	Pipe O.D. 2 (inch)	1-1/2
Pipe O.D. (inch)	4	Pipe O.D. (mm)	100
