Parker RR63 L8N12 - Transair® Drop Brackets for Aluminum Pipe

Transair® Drop Brackets are designed for the quick and easy addition of drop lines to an existing compressed air pipe or inert gas system.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. RR63 L8N12

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Minimum Operating Temperature	-4 °F	Connection 2 Type	NPT
Connection 1 Size	6 inch	Maximum Operating Pressure	13 bar 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/ca/en/crn/transair.html
Weight	7,5 kg	Specifications Met	EN 755.8
For Fluid Type	Air	Brand	Parker
Industry	General Industrial	Connection 2 Size	1-1/2 inch
Technology	Pneumatics	Division	Fluid System Connectors Division
Silicone Free	Yes	Assembly Time	0.1 Hours
Product Type	Compressed Air Piping	Configuration	Pipe to Port
Body Material	Cast Iron	Vacuum Pressure Rating	1.0 mbar
Product Style	Quick Assembly Bracket	Shape	Saddle
Division	Fluid System Connectors Division	Plating Type	Zinc-plated
Assembly	Drop	Quantity per Box	1
Connection 1 Type	Pipe	Application	Industrial Gas
Maximum Operating Temperature	185 °F	Body Material	Cast Iron / Zinc-plated
Connection 2 Type	Female Threaded NPT Saddle Reducing Bracket	Connection 1 Size	6" (168 mm)
Connection 2 Size	1-1/2"
