Parker RA68 40N04 - Transair® Drop Brackets for Aluminum Pipe

Transair® Drop Brackets are designed for the quick and easy addition of drop lines to an existing compressed air pipe or inert gas system.

Availability:	Quote Required
Partner Available:	183 In Stock

Brand Parker

Part No. RA68 40N04

$42.06

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Brand	Parker
Product Type	Compressed Air Piping	Maximum Operating Temperature	85 °C
Minimum Operating Temperature	-20 °C	Industry	General Industrial
Division	Fluid System Connectors Division	Division	Low Pressure Connectors Europe Division
Application	Compressed Air	Technology	Pneumatics
Quantity per Box	5	Specifications Met	ASME B31.1 - 31.9
Maximum Operating Pressure	232 psi	For Fluid Type	Air
Connection 1 Type	Pipe	Connection 2 Type	NPT
Connection 2 Size	1/2 inch	Body Material	Technical Polymer
Connection 1 Size	40 mm	Configuration	Pipe to Port
Assembly Time	0.07 Hours	Product Style	Quick Assembly Bracket
Vacuum Pressure Rating	1.0 mbar 99,9% (absolute pressure)	Assembly	Drop
Silicone Free	Yes	Shape	Simple Reducing
Weight	0,42 lb	Connection 2 Size	1/2"
Body Material	Technical Polymer	Connection 1 Size	1-1/2" (40 mm)
Connection 2 Type	Female Threaded NPT Simple Reducing Bracket
