Parker RA31 V1200-SF - Transair® Fittings for Aluminum Pipe

Transair Fittings install fast and with minimal tooling required. All Transair fittings are designed to securely fit around Transair aluminum pipe, increasing system efficiency and preventing compressed air leaks.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. RA31 V1200-SF

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Brand	Parker	Product Type	Compressed Air Piping
Division	Fluid System Connectors Division	Shape	Straight
Minimum Operating Temperature	-20 °C	Industry	General Industrial
Technology	Fluid & Gas Handling	Division	Fluid System Connectors Division
Application	Vacuum	Body Material	Treated Aluminum
Vacuum Pressure Rating	1 mbar	Maximum Operating Temperature	60 °C
For Fluid Type	Industrial Gas	Connection 1 Type	Pipe
Quantity per Box	1	Connection 1 Size	8 inch
Weight	7.529 kg	Assembly Time	0.41 Hours
Configuration	Pipe to Flange	Product Style	ANSI Flange Adapter
Connection 2 Size	220 mm	Connection 2 Type	Flange
Specifications Met	ASME B31.1 - 31.3	Maximum Operating Pressure	10 bar 150 PSI (-4° to +140°F)/10 bar (-20°C to 60°C) For Canada, Please refer to https://www.parker.com/ca/en/crn/transair.html
Connection Thread Size (inch)	n/a	Silicone Free	Yes
Pipe O.D. 2 (mm)	N/A	Pipe O.D. 2 (inch)	N/A
Pipe O.D. (mm)	220	Pipe O.D. (inch)	8
Product Style	Flange
