Parker RA30 63 00 - Transair® Fittings for Aluminum Pipe

Transair Fittings install fast and with minimal tooling required. All Transair fittings are designed to securely fit around Transair aluminum pipe, increasing system efficiency and preventing compressed air leaks.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. RA30 63 00

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Brand	Parker	Product Type	Compressed Air Piping
Shape	Straight	Minimum Operating Temperature	-4 °F
Industry	General Industrial	Technology	Fluid & Gas Handling
Division	Fluid System Connectors Division	Division	Low Pressure Connectors Europe Division
Application	Compressed Air	Body Material	Treated Aluminum
Specifications Met	EN 755.2	Vacuum Pressure Rating	1 mbar
Maximum Operating Pressure	16 bar 232 PSI (-4°F to +113°F)/16 bar (-20°C to 45°C) up to 100 mm 188 PSI (-4° to +140°F)/13 bar (-20°C to 60°C) up to 168 mm 101 PSI (-4° to +185°F)/7 bar ( -20°C to 85°C) up to 168 mm For Canada, Please refer to https://www.parker.com/ca	Maximum Operating Temperature	185 °F
For Fluid Type	Air	Connection 1 Type	Pipe
Quantity per Box	1	Connection 1 Size	2-1/2 inch
Assembly Time	0.17 Hours	Connection 2 Size	63 mm
Weight	1.798 kg	Configuration	Pipe to Flange
Product Style	ISO Flange Adapter	Connection 2 Type	Flange
Pipe O.D. (mm)	63	Pipe O.D. (inch)	2-1/2
Connection Thread Size (inch)	n/a	Silicone Free	Yes
Pipe O.D. 2 (mm)	N/A	Pipe O.D. 2 (inch)	N/A
Product Style	Flange
