Parker RA12 V1200-SF - Transair® Fittings for Aluminum Pipe

Transair Fittings install fast and with minimal tooling required. All Transair fittings are designed to securely fit around Transair aluminum pipe, increasing system efficiency and preventing compressed air leaks.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. RA12 V1200-SF

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Brand	Parker	Product Type	Compressed Air Piping
Division	Fluid System Connectors Division	Minimum Operating Temperature	-20 °C
Industry	General Industrial	Technology	Fluid & Gas Handling
Division	Fluid System Connectors Division	Body Material	Treated Aluminum
Configuration	Pipe to Pipe	Vacuum Pressure Rating	0.03 inch-Hg
Maximum Operating Temperature	185 °F	For Fluid Type	Air
Connection 1 Type	Pipe	Maximum Operating Pressure	150 psi
Quantity per Box	1	Connection 2 Type	Pipe
Shape	Elbow 90°	Application	Inert Gas
Product Style	Union Fitting	Connection 1 Size	8 inch
Weight	3.719 kg	Assembly Time	0.39 Hours
Connection 2 Size	8 inch	Specifications Met	ASME B31.1 - 31.3
Connection Thread Size (inch)	n/a	Silicone Free	Yes
Product Style	Pipe	Pipe O.D. 2 (mm)	N/A
Pipe O.D. 2 (inch)	N/A	Pipe O.D. (mm)	220
Pipe O.D. (inch)	8
