| Division | Fluid System Connectors Division | Specifications Met | N/A |
| Seal Material | PTFE | Minimum Operating Temperature | 0 °F |
| Connection Type | NPT | Maximum Operating Temperature | 93 °C |
| Function | 2-Way | Actuation Type | Manual |
| Seat Material | PTFE | Maximum Operating Pressure | 450 psi |
| Product Type | Ball Valve | Handle Type | Compact |
| Operation Type | On/Off | Orifice Size | n/a |
| Mounting Type | In-Line | Body Material | Chrome Plated Brass |
| Configuration | In-line | Lock Type | Non-Locking |
| Ball Material | Chrome Plated Brass | Connection Size | 3/8 x 1/4 inch |
| Maximum Flow Rate | 3.6 Cv | Connection 2 Thread Size (inch) | 1/4 |
| Connection 1 Thread Size (inch) | 3/8 | Style | Female Pipe Ends |
| Connection 1 Thread Style | Female Pipe | Connection 2 Thread Style | Female Pipe |
| Handle | Polyamide Wedge Lever | Vacuum Rating (inch of Hg) | 28 |
| Maximum Working Pressure (Bar) | 31 | Maximum Working Pressure (psi) | 450 |
