Parker MMHOMDS4L6098564151 - MESC Compliant Modular Manifolds

Parker's modular range of manifolds and accessories for small-bore instrumentation requirements that allow anyone to configure and order a complete integrated manifold and mounting solution for a process application in a few minutes.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. MMHOMDS4L6098564151

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
MESC Number	609856.415.1	Bolt Material	ASTM A193-B8 CL2
Specifications Met	ISO 10474-3.1B	Outlet Connection Size	IEC 61518
Division	Instrumentation Products Division	Maximum Operating Pressure	413
Packing Material	Graphite	Vent Size	10 mm
Number of Valves	4 Valve	Maximum Operating Temperature	538
Connection Type	Two Ferrule Compression Fitting	Block Type	Double Isolate/Vent
Process/Vent Size	10 mm	Outlet Connection	IEC 61518
Material	316 Stainless Steel	Connection Type	Two Ferrule Compression Fitting
MESC Number	609856.415.1
