Parker LQX12-2W12FF48-001 - LQX12 - 12 mm Miniature Diaphragm Isolation Valve

Parker's LQX12 family of 12 mm diaphragm isolation valves offer metal free wetted paths with EPDM and FFKM versions to meet the needs of your applications.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. LQX12-2W12FF48-001

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Out of Stock Lead Time	40	Power Consumption	2.0 Watts Maximum
Height	1.57 inch	Connection Type	Threaded Port Connections
Actuation Type	Solenoid	Configuration	n/a
Body Material	PEEK	Division	Precision Fluidics Division
Width	12 mm	Maximum Operating Temperature	50 °C
Shipping Weight	0.35	Flow Rate	Up to 700 sccm
Function	2-Way Normally Closed (NC)	Weight	76.5 g
Industry Application	Solvent management for Liquid Chromatography, Highly aggressive media dispensing and control	Electrical Connection	18" Wire Leads
Leak Rate	Bubble Tight	Vacuum to Pressure Range	Vac to 50 psig
For Fluid Type	Liquids	Max Order Quantity	9
Operation Type	Electronic	Maximum Operating Pressure	3.4 bar
Response Time	< 20 ms (2-Way), < 12 ms (3-Way)	Minimum Operating Temperature	0 °C
Valve Type	Diaphragm Rocker Isolation Valve	Standard Lead Time	20
Orifice Size	1.02 mm	Connection Size	1/4"- 28 UNF 2B
Seal Material	FFKM	Maximum Flow Rate	700 sccm
Cycles per Lifetime	10 Million	Mounting Type	Mounting Screw
Input Voltage	12 VDC	Control Method	Current or Voltage
Length	1.16 inch	Mounting Style	1/4" -28
Valve Configuration Type	2-Way Normally Closed	Voltage (VDC)	12
Chemical Resistance Required	High - PEEK Body, FFKM Diaphragm	Electrical Connection	18" Flying Leads
