Parker K3/16L1-G230M - CO2-free Laboratory Gas Generator - K-MT LAB Series

Parker K-MT-LAB Series CO2-free Gas Generators provide cleanroom air for many GC or TOC applications, at flow rates between 1.5 and 175 Nl/min.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. K3/16L1-G230M

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Ambient Temperature	41 to 122 °F	Operating Pressure	58 to 232 psig
Ingress Protection Rating	IP65	Division	Gas Separation and Filtration Division EMEA
Industry	Healthcare & Life Sciences	Technology	Filtration
Product Type	CO2 Free Gas Generator	Dew Point	-40
Port Type	BSPP	Application	Analytical Laboratory
Noise Level	65 to 86 dBA	Product Series	K-MT LAB
Specifications Met	PED 2014/68/EU Fluid Group II	Brand	Parker
Division	Gas Separation and Filtration Division EMEA	Flow Rate	20 l/min @7 barg (0.7 cfm @102 psig)
Port Size	¼ inch
