| Connection Size | n/a | Connection Type | n/a |
| Seal Material | Fluorocarbon | Body Material | n/a |
| Division | Hydraulic Valve Systems Division | Division | Hydraulic Systems Division |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Minimum Operating Temperature | -15 |
| Flow Rate | 9.5 | Maximum Operating Pressure | 3000 |
| Weight | 0.28 | Coil Type | 5/8" Super Coil High Watt (CAP) |
| Installation Torque | 22 | Coil Nut Tightening Torque | 3 |
| Maximum Inlet Pressure Rating | 3000 | Function | Proportional Flow Control/Regulator |
| Actuation Type | Electrical, Manual | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Operation Type | Solenoid operated, Manually operated | Valve Material | All parts steel. All operating parts hardened steel |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Wire Mesh Screen Included | No |
| Variation of Opening Point | N/A | Operating Temperature | -15 to +400 |
| Current | Max: 2.33 @ 12 VDC, 1.17 @ 24 VDC | Frequency | 100-400 |
| Power Consumption | 28 | Maximum Operating Temperature | +400 |
| Minimum Pressure Differential | 200 | Cavity Size | 3X |
| Flow Direction | Top to Side (3 - 2) | Flow Rate Accuracy | Up to 20% |
| Configuration | Normally Open, Pressure Compensated | Leak Rate | 780 @ 3000 PSI (210 BAR) |
| Hysteresis | 7% | Maximum Flow Rate | 9.5 |
| Override Functionality | Infininte Control | Variation of Closing Point | 25% of Input Signal |
| Seal Material | Fluorocarbon | Actuation Type | Electrical, Manual |
| Flow Rate | 9.5 GAL/MIN, 36 L/MIN | Configuration | Normally Open, Pressure Compensated |
