| Actuation Type | Electrical | Seal Material | Nitrile |
| Connection Size | n/a | Connection Type | n/a |
| Body Material | n/a | Division | Hydraulic Cartridge Systems Division |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Maximum Operating Pressure | 210 bar | Minimum Operating Temperature | -34 °C |
| Weight | 0.28 lb | Override Functionality | n/a |
| Coil Type | 5/8" Super Coil High Watt (CAP) | Operation Type | Solenoid Operated |
| Power Consumption | 28 W | Installation Torque | 30 Nm |
| Coil Nut Tightening Torque | 4.1 Nm | Maximum Inlet Pressure Rating | 210 bar |
| Maximum Operating Temperature | +121 °C | Function | Proportional Flow Control/Regulator |
| Frequency | 100-400 Hz | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Operating Temperature | -30 to +250 °F |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Wire Mesh Screen Included | No |
| Variation of Opening Point | N/A | Cavity Size | 3X |
| Flow Direction | Top to Side (3 - 2) | Flow Rate Accuracy | +/- 7% |
| Current | Max: 2.33 @ 12 VDC, 1.17 @ 24 VDC A | Configuration | Normally Open, Pressure Compensated |
| Flow Rate | 36 L/min | Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min |
| Hysteresis | 7% | Maximum Flow Rate | 9.5 Gal/min |
| Variation of Closing Point | 25% of Input Signal | Minimum Pressure Differential | 200 psi |
| Seal Material | Nitrile | Actuation Type | Electrical |
| Flow Rate | 9.5 GAL/MIN, 36 L/MIN | Configuration | Normally Open, Pressure Compensated |
