| UOM | EA | Minimum Operating Temperature | -30 °F |
| Division | Hydraulic Systems Division | Operating Temperature | -34 to +121 °C |
| Operation Type | Solenoid operated, Manually operated | Flow Rate | 30, 36 L/min |
| Current | Max: 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A | Installation Torque | 30 Nm |
| Connection Size | N/A | Seal Material | Nitrile |
| Actuation Type | Electrical, Manual | Flow Rate Accuracy | +/- 7% |
| Coil Nut Tightening Torque | 3 lb-ft | Weight | 0.13 kg |
| Power Consumption | 18, 28 W | Wire Mesh Screen Included | No |
| Maximum Operating Pressure | 3000 psi | Maximum Inlet Pressure Rating | 3000 psi |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Valve Material | All parts steel. All operating parts hardened steel |
| Flow Direction | Top to Side (3 - 2) | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Function | Proportional Flow Control/Regulator | Configuration | Normally Closed, Pressure Compensated |
| Frequency | 100-400 Hz | Division | Hydraulic Cartridge Systems Division |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Hysteresis | 7% |
| Cavity Size | 3X | Maximum Operating Temperature | +121 °C |
| Connection Type | N/A | Variation of Closing Point | N/A |
| Override Functionality | Infinite Control | Coil Type | 5/8" Super Coil |
| Variation of Opening Point | 25% of Input Signal | Maximum Flow Rate | 8, 9.5 Gal/min |
| Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min | Minimum Pressure Differential | 200, 300 psi |
| Body Material | N/A | Seal Material | Nitrile |
| Actuation Type | Electrical, Manual | Configuration | Normally Closed, Pressure Compensated |
| Flow Rate | 8, 9.5 GAL/MIN, 30, 36 L/MIN | | |
