| Maximum Operating Pressure | 3000 psi | Seal Material | Nitrile |
| Connection Size | n/a | Connection Type | n/a |
| Body Material | n/a | Division | Hydraulic Cartridge Systems Division |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -34 °C | Weight | 0.08 kg |
| Maximum Inlet Pressure Rating | 3000 psi | Coil Nut Tightening Torque | 4.1 Nm |
| Cavity Size | C08-3 | Maximum Operating Temperature | +121 °C |
| Function | Proportional Flow Control/Regulator | Frequency | 100-400 Hz |
| Actuation Type | Electrical, Manual | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Operation Type | Solenoid operated, Manually operated | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -30 to +250 °F | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Wire Mesh Screen Included | No | Variation of Closing Point | N/A |
| Configuration | Normally Closed, Pressure Compensated | Override Functionality | Infinite Control |
| Coil Type | 1/2" Super Coil | Installation Torque | 20 lb-ft |
| Flow Direction | Top to Side (3 - 2) | Power Consumption | 14, 19 W |
| Flow Rate Accuracy | Up to 20% | Variation of Opening Point | 25% of Input Signal |
| Current | Max: 1.15 @ 12 VDC, 1.58 @ 12 VDC, 0.58 @ 24 VDC, 0.79 @ 24 VDC A | Flow Rate | 4, 6 Gal/min |
| Leak Rate | 570 @ 3000 PSI (210 BAR) cm3/min | Hysteresis | < 3%, < 10% |
| Maximum Flow Rate | 15, 23 L/min | Minimum Pressure Differential | 13.8, 20.7 bar |
| Seal Material | Nitrile | Actuation Type | Electrical, Manual |
| Configuration | Normally Closed, Pressure Compensated | Flow Rate | 4, 6 GAL/MIN, 15, 23 L/MIN |
