| UOM | EA | Actuation Type | Electrical |
| Seal Material | Nitrile | Connection Size | n/a |
| Connection Type | n/a | Weight | 0.17 |
| Body Material | n/a | Minimum Operating Temperature | -30 |
| Division | Hydraulic Valve Systems Division | Division | Hydraulic Systems Division |
| Flow Direction | Bi-directional | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Maximum Operating Pressure | 3000 | Override Functionality | n/a |
| Coil Type | 1/2" Super Coil High Watt (CCP) | Operation Type | Solenoid Operated |
| Power Consumption | 19 | Coil Nut Tightening Torque | 3 |
| Maximum Inlet Pressure Rating | 3000 | Function | Proportional Flow Control/Regulator |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Valve Material | All parts steel. All operating parts hardened steel |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Wire Mesh Screen Included | No |
| Variation of Opening Point | N/A | Operating Temperature | -30 to +250 |
| Frequency | 100-400 | Maximum Operating Temperature | +250 |
| Installation Torque | 15 | Hysteresis | < 10% |
| Flow Rate | 4, 5 | Maximum Flow Rate | 4, 5 |
| Current | Max: 1.58 @ 12 VDC, 0.79 @ 24 VDC | Leak Rate | 1135 @ 3000 PSI (210 BAR) |
| Cavity Size | 2X | Configuration | Normally Open, Partially Pressure Compensated |
| Flow Rate Accuracy | Up to 20% | Variation of Closing Point | 75% of Input Signal |
| Minimum Pressure Differential | N/A | Seal Material | Nitrile |
| Actuation Type | Electrical | Flow Rate | 4, 5 GAL/MIN, 15, 19 L/MIN |
| Configuration | Normally Open, Partially Pressure Compensated | | |
