| Actuation Type | Electrical | Connection Size | n/a |
| Connection Type | n/a | Weight | 0.17 |
| Seal Material | Fluorocarbon | Body Material | n/a |
| Division | Hydraulic Valve Systems Division | Division | Hydraulic Systems Division |
| Flow Direction | Bi-directional | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -15 | Maximum Operating Pressure | 3000 |
| Override Functionality | n/a | Operation Type | Solenoid Operated |
| Coil Nut Tightening Torque | 3 | Maximum Inlet Pressure Rating | 3000 |
| Function | Proportional Flow Control/Regulator | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Wire Mesh Screen Included | No | Variation of Closing Point | N/A |
| Operating Temperature | -15 to +400 | Frequency | 100-400 |
| Maximum Operating Temperature | +400 | Installation Torque | 15 |
| Coil Type | 1/2" Super Coil | Hysteresis | < 10% |
| Power Consumption | 14, 19 | Maximum Flow Rate | 2.5, 3.5, 4, 6 |
| Flow Rate | 2.5, 3.5, 4, 6 | Current | Max: 1.15 @ 12 VDC, 1.58 @ 12 VDC, 0.58 @ 24 VDC, 0.79 @ 24 VDC |
| Leak Rate | 946 @ 3000 PSI (210 BAR) | Cavity Size | 2X |
| Configuration | Normally Closed, Partially Pressure Compensated | Flow Rate Accuracy | Up to 20% |
| Variation of Opening Point | 25% of Input Signal | Minimum Pressure Differential | N/A |
| Seal Material | Fluorocarbon | Actuation Type | Electrical |
| Flow Rate | 2.5, 3.5, 4, 6 GAL/MIN, 9.5, 13.3, 15, 22.8 L/MIN | Configuration | Normally Closed, Partially Pressure Compensated |
