*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker H9CP - Industrial Interchange Nipples, ISO 6150-B, Air Plug

Name: Parker H9CP - Industrial Interchange Nipples, ISO 6150-B, Air Plug
SKU: H9CP
Price: 6.32 USD
Availability: InStock

Parker's general purpose, Industrial Interchange quick connect air nipples (plugs) are ideal for use across a spectrum of applications where low pressure air or fluid lines require fast and easy connection and disconnection.

AFP Availability:

313 In Stock

Richmond, VA	159
Norfolk, VA	75
Jacksonville, FL	30
Knoxville, TN	15
Fayetteville, NC	11
Knoxville, TN	10
Mooresville, NC	6
Richmond, VA	2 (Pickup only)
Ashland, VA	2 (Pickup only)
Johnson City, TN	2 (Pickup only)
Summerville, SC	1

Partner Available:

1665 In Stock

Brand Parker

Part No. H9CP

$6.32/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Valve Type	Unvalved
Media	Low pressure fluids and compressed air	Coupling Half	Nipple
Plating Type	Zinc with clear trivalent chromate	Specifications Met	A-A-59439 (MIL-C-4109F, ISO 6150-B)
Division	Quick Coupling Division	Application	Air
Maximum Operating Pressure	300 psi	Dimensional Weight	0.013329336530775381 lb
Body Material	Steel	Connection Type	Push-Lok hose barb
Body Material	Steel	Connection Hose I.D. (inch)	3/8
Thread Style	na	Body Size (inch)	1/4
Connection Thread Size (inch)	na
