Parker H1-63 - General Purpose, ISO 7241-B, Hydraulic Quick Couplings - 60 Series

Name: Parker H1-63 - General Purpose, ISO 7241-B, Hydraulic Quick Couplings - 60 Series
SKU: H1-63
Price: 11.76 USD
Availability: InStock

Parker's general purpose quick couplers and nipples are versatile for use across a spectrum of applications where fluid, gas or steam lines require fast and easy connection and disconnection.

AFP Availability:

35 In Stock

East Knoxville, TN	10
West Knoxville, TN	6
Johnson City, TN	4 (Pickup only)
North Chesterfield, VA	2
Richmond, VA	2 (Pickup only)
Ashland, VA	2 (Pickup only)
Norfolk, VA	2
Jacksonville, FL	2
Sumter, SC	2
Mooresville, NC	2
Summerville, SC	1

Partner Available:

426 In Stock

Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

Brand Parker

Part No. H1-63

$11.76/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Valve Material	Steel
Division	Quick Coupling Division	Maximum Operating Temperature	121 °C
Vacuum Pressure Rating	-0.9 bar	Valve Type	Poppet
Dimensional Weight	0.02670863309352518 lb	Hex Size	0.56 inch
Body Material	Steel	Flow Rate	0.8 Gal/min
Specifications Met	ISO 7241-1 Series B	Minimum Operating Temperature	-40 °C
Product Type	Manual Connect	Plating Type	Zinc with Clear Trivalent Chromate
Connection Type	Female NPTF	Maximum Operating Pressure	5000
Application	General Purpose	Body Size (inch)	1/8
Body Material	Steel	Connection Thread Size (inch)	1/8 - 27
Coupling Half	Male Nipple	Seal Material	Nitrile

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
