| Division | Hydraulic Systems Division | Hysteresis | 3.5% |
| Wire Mesh Screen Included | Yes | Maximum Operating Temperature | +121 °C |
| Body Material | n/a | Mounting Type | Screw in cartridge valve |
| Flow Direction | Inlet port 3, Reducing port 2, Tank port 1 | Division | Hydraulic Cartridge Systems Division |
| Leak Rate | N/A cm3/min | Override Functionality | n/a |
| Coil Type | 1/2" Super Coil High Watt (CCP) | Valve Material | All parts steel. All operating parts hardened steel |
| Maximum Inlet Pressure Rating | 3000 psi | Current | 1.4 at 12VDC (High watt), 0.7 at 24VDC (High watt) A |
| Operating Temperature | -30 to +250 °F | Cavity Size | C08-3 |
| Minimum Operating Temperature | -34 °C | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Seal Material | Nitrile |
| Weight | 0.17 lb | Maximum Flow Rate | 19 L/min |
| Coil Nut Tightening Torque | 3 lb-ft | Installation Torque | 27 Nm |
| Flow Rate | 5 Gal/min | Actuation Type | Electrical |
| Maximum Operating Pressure | 210 bar | Maximum Pressure Setting | N/A psi |
| Frequency | 100-400 Hz | Maximum Tank Pressure | N/A psi |
| Function | Proportional Pressure Reducing | Response Time | 10 ms |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Power Consumption | 19 W |
| Maximum Drain Flow Rate | 100 De-Energized, 750 In Regulating Zone @ 300 PSI (21 BAR) cm3/min | Operation Type | Solenoid Operated |
| Maximum Regulating Pressure | 180-240 psi | Configuration | Side Cylinder Port |
| Wire Mesh Screen Included | Yes | Configuration | Side Cylinder Port |
| Maximum Regulating Pressure | 180-240 PSI, 12-17 BAR | Maximum Flow Rate | 5 GAL/MIN, 19 L/MIN |
| Override Functionality | N/A | Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR |
| Seal Material | Nitrile | | |
