| Actuation Type | Electrical | Weight | 0.17 |
| Seal Material | Fluorocarbon | Body Material | n/a |
| Division | Hydraulic Valve Systems Division | Division | Hydraulic Systems Division |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Minimum Operating Temperature | -15 |
| Maximum Operating Pressure | 3000 | Override Functionality | n/a |
| Maximum Pressure Setting | n/a | Wire Mesh Screen Included | Yes |
| Leak Rate | n/a | Operation Type | Solenoid Operated |
| Coil Nut Tightening Torque | Finger Tight | Maximum Inlet Pressure Rating | 3000 |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Valve Material | All parts steel. All operating parts hardened steel |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Operating Temperature | -15 to +400 |
| Frequency | 100-400 | Maximum Operating Temperature | +400 |
| Mounting Type | Screw in cartridge valve | Function | Proportional Pressure Reducing |
| Flow Direction | Inlet port 2, Reducing port 1, Tank port 3 | Installation Torque | 20 |
| Flow Rate | 1.9 | Configuration | Bottom Cylinder Port |
| Maximum Flow Rate | 0.5 | Current | 1.1 at 12VDC (Low watt), 1.4 at 12VDC (High watt), 0.6 at 24VDC (Low watt), 0.7 at 24VDC (High watt) |
| Coil Type | 1/2" Super Coil High Watt (CCP), 1/2" Super Coil Low Watt (CCS) | Hysteresis | 2% |
| Cavity Size | 54-1 | Response Time | 10 (Off), 30 (On) |
| Power Consumption | 14, 19 | Maximum Tank Pressure | 440 |
| Maximum Drain Flow Rate | 5 De-Energized, 200 In Regulating Zone @ 1000 PSI (68 BAR) | Maximum Regulating Pressure | 250 (Low Watt), 320 (High Watt) |
| Seal Material | Fluorocarbon | Override Functionality | N/A |
| Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR | Wire Mesh Screen Included | Yes |
| Configuration | Bottom Cylinder Port | Maximum Flow Rate | 0.5 GAL/MIN, 1.9 L/MIN |
| Maximum Regulating Pressure | 250 PSI, 17 BAR Standard, or 320 PSI, 22 BAR High Pressure | | |
