Parker FG-K1-124-KW - Fuel Drip Bunker Samplers

Parker bunker samplers are designed to provide a representative sample of the entire fuel delivery. Manufactured from stainless steel.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. FG-K1-124-KW

$2,471.63/each

Products specifications

Attribute name	Attribute value
UOM	EA	Division	Hydraulic & Industrial Process Filtration Division EMEA
Sensing Range	n/a	Connection Type	Multiple line diameter versions from 50 mm to 350 mm
Technology	Hydraulics	For Fluid Type	Lube Oil Fuel
Accuracy	n/a	Accessories Included	Sample containers, anti-tamper locks, bottle seals and labels available separately
Cycle Time	n/a	Signal Output	n/a
Communication Interface	n/a	Ingress Protection Rating	n/a
Options	Wide range of line diameters: 50 mm (2") up to 300 mm (12") in 25 mm (1")	Size	515 to 840 x 31.5 x 95 to 401 mm (Height x Width x Diameter)
Operating Pressure	40 bar	Flow Rate	n/a
Electrical Requirements	n/a	Sensor Connection	n/a
Wetted Material	Stainless steel, PTFE, non-asbestos grade Y gasket (aramid/glass fibres and nitrile rubber)	Product Type	Sampling System
Operating Temperature	-50 to 75 °C	Division	Hydraulic & Industrial Process Filtration Division EMEA
Industry	Marine	Brand	Kittiwake
Features	Simple and effective continuous fuel sampling for the entire delivery as ISO 13739<br/>ASTM D 4057: 2000 Standard practice for manual sampling of petroleum and petroleum products	Sensing Method	n/a
Weight	3 to 12	Quantity per Box	1
Pipe Outside Diameter	100 mm	Product Style	Drip Sampler
