Parker FEM-252-4FP - Flat Face, ISO 16028, Hydraulic Quick Couplings - FEM Series

Parker's non-spill, flat face hydraulic couplers are ideal for use across a variety of applications where fluid lines require fast & easy connection and disconnection. These quick connect fittings are designed to minimize spillage and limit air inclusion

Availability:	Quote Required
Partner Available:	79 In Stock

Brand Parker

Part No. FEM-252-4FP

$52.43

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Product Type	Push to Connect
Body Material	Steel	Flow Rate	11 L/min
Plating Type	Zink Nickel	Specifications Met	ISO 16028
Dimensional Weight	0.02670863309352518 lb	Minimum Operating Temperature	-40 °C
Hex Size	27 mm	Seal Material	NBR
Application	n/a	Division	Quick Coupling Division
Maximum Operating Temperature	110 °C	Valve Type	Non-spill
Connection Thread Size (inch)	1/4 - 18	Connection Type	Female NPSF
Maximum Operating Pressure	4568	Body Size (inch)	1/4
Coupling Half	Male Nipple

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
