Parker FD07DD30ND - Throttle Sandwich Valve with Check - FC, FD Series

Parker’s FC, FD series throttle check valves are designed for maximum flow rates.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. FD07DD30ND

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Filter Efficiency Rating	ISO 4406 (1999); 18/16/13 (meet NAS 1638:7)	Actuation Type	Hydrau;ic Pressure
Division	Hydraulic Valve Systems Division	Media	Oil
Allowable Circuit Leakage	<5 DPM	Port Connection	A and B control
Cracking Pressure	30 ± 0.3 bar	Mounting Type	Subplate
Minimum Operating Temperature	-4 °F	Product Style	Throttle Valve with Check
Maximum Operating Temperature	+122 °F	Weight	15.3 lb
Maximum Flow Rate	60 Gal/min	Body Material	Ductile Iron
Maximum Operating Pressure	345 bar	Seal Material	Nitrile
Size	NFPA D07; CETOP 7; NG16	Flow Meter	Meter-In
Maximum Operating Pressure	5000 PSI
