| Actuation Type | Electrical | Seal Material | Fluorocarbon |
| Body Material | n/a | Division | Hydraulic Cartridge Systems Division |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -15 °F | Weight | 0.25 kg |
| Override Functionality | n/a | Maximum Operating Pressure | 350 bar |
| Wire Mesh Screen Included | n/a | Maximum Inlet Pressure Rating | 350 bar |
| Operation Type | Solenoid Operated | Cavity Size | C08-3L |
| Configuration | Pressure Reducing/Relieving | Installation Torque | 43-49 Nm |
| Maximum Operating Temperature | +204 °C | Hysteresis | 4% |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -26 to +204 °C | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Mounting Type | Screw in cartridge valve | Maximum Flow Rate | 22.7 L/min |
| Maximum Tank Pressure | N/A psi | Current | 0.73 at 12VDC, 0.365 at 24VDC A |
| Function | Proportional Pressure Reducing | Coil Type | SW7L Standard Short Coil |
| Flow Rate | 22.7 L/min | Frequency | 200-600 Hz |
| Leak Rate | 230 De-Energized cm3/min | Response Time | N/A ms |
| Flow Direction | Inlet port 2, Reducing port 1, Tank port 3 | Power Consumption | 8.4 @ Max Reduced Pressure W |
| Maximum Drain Flow Rate | N/A cm3/min | Maximum Pressure Setting | N/A psi |
| Coil Nut Tightening Torque | 7-9.5 Nm | Maximum Regulating Pressure | 1000 psi |
| Seal Material | Fluorocarbon | Override Functionality | N/A |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Configuration | Pressure Reducing/Relieving |
| Maximum Flow Rate | 6 GAL/MIN, 22.7 L/MIN | Wire Mesh Screen Included | N/A |
| Maximum Regulating Pressure | 1000 PSI, 68.9 BAR | | |
