| UOM | EA | Coil Type | 5/8" Super Coil |
| Cavity Size | C10-3 | Override Functionality | N/A |
| Maximum Operating Temperature | +204 °C | Leak Rate | 120 @ 3600 PSI (250 BAR) cm3/min |
| Mounting Type | Screw in cartridge valve | Input Voltage | 85% of rated voltage at 72°F (20°C) min |
| Operation Type | Solenoid operated | Maximum Flow Rate | 6 Gal/min |
| Body Material | N/A | Minimum Operating Temperature | -26 °C |
| Installation Torque | 50-56 Nm | Operating Temperature | -26 to +204 °C |
| Division | Hydraulic Systems Division | Flow Rate | 17, 22.7 L/min |
| Response Time | 50-100 ms | Maximum Operating Pressure | 250 bar |
| Seal Material | Fluorocarbon | Weight | 0.19 kg |
| Coil Nut Tightening Torque | 7-10 Nm | Actuation Type | Electrical |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Maximum Inlet Pressure Rating | 3600 psi | Valve Material | All parts steel. All operating parts hardened steel |
| Flow Direction | 2-1 De-energized, 3-1 Energized | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Function | 3-way | Configuration | Normally Closed, Normally Open, Selector |
| Seal Material | Fluorocarbon | Actuation Type | Electrical |
| Configuration | Normally Closed, Normally Open, Selector | Flow Direction | 2-1 De-energized, 3-1 Energized |
| Maximum Inlet Pressure Rating | 3600 PSI, 250 BAR | Flow Rate | 4.5, 6 GAL/MIN, 17, 22.7 L/MIN |
