| Maximum Flow Rate | 6 | Seal Material | Nitrile |
| Body Material | n/a | Minimum Operating Temperature | -30 |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Function | 3-Way | Weight | 0.42 |
| Cavity Size | C10-3 | Actuation Type | Electrical, Manual |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Operation Type | Solenoid operated, Manually operated |
| Valve Material | All parts steel. All operating parts hardened steel | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Maximum Operating Temperature | +250 | Mounting Type | Screw in cartridge valve |
| Configuration | Normally Closed, Normally Open, Selector | Input Voltage | 85% of rated voltage at 72°F (20°C) |
| Coil Nut Tightening Torque | 5-7 | Flow Direction | 2-1 De-energized, 3-1 Energized |
| Operating Temperature | -34 to +121 | Coil Type | 5/8" Super Coil |
| Response Time | 50-100 | Override Functionality | Pull and Release |
| Maximum Operating Pressure | 3600 | Maximum Inlet Pressure Rating | 3600 |
| Leak Rate | 120 @ 3600 PSI (250 BAR) | Installation Torque | 37-41 |
| Flow Rate | 4.5, 6 | Seal Material | Nitrile |
| Actuation Type | Electrical, Manual | Configuration | Normally Closed, Normally Open, Selector |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Maximum Inlet Pressure Rating | 3600 PSI, 250 BAR |
| Flow Rate | 4.5, 6 GAL/MIN, 17, 22.7 L/MIN | | |
