| UOM | EA | Actuation Type | Electrical |
| Body Material | n/a | Division | Hydraulic Systems Division |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Minimum Operating Temperature | -35 °F |
| Function | 3-Way | Override Functionality | n/a |
| Maximum Operating Pressure | 350 bar | Maximum Flow Rate | 8 Gal/min |
| Maximum Inlet Pressure Rating | 350 bar | Seal Material | D-Ring (Standard) |
| Operation Type | Solenoid Operated | Cavity Size | C10-3 |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Valve Material | All parts steel. All operating parts hardened steel |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Leak Rate | 250 @ 5000 PSI (350 BAR) cm3/min |
| Mounting Type | Screw in cartridge valve | Operating Temperature | -35 to +200 °F |
| Maximum Operating Temperature | +93 °C | Configuration | Normally Closed, Normally Open, Selector |
| Input Voltage | 85% of rated voltage at 72°F (20°C) min | Coil Nut Tightening Torque | 7-10 Nm |
| Flow Direction | 2-3 De-energized, 2-1 Energized | Coil Type | 5/8" Super Coil |
| Installation Torque | 69-75 Nm | Weight | 0.19 kg |
| Flow Rate | 4, 8 Gal/min | Response Time | 50-100 ms |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Seal Material | D-Ring (Standard) |
| Actuation Type | Electrical | Configuration | Normally Closed, Normally Open, Selector |
| Flow Direction | 2-3 De-energized, 2-1 Energized | Flow Rate | 4, 8 GAL/MIN, 15, 30 L/MIN |
