| Actuation Type | Electrical | Seal Material | Fluorocarbon |
| Body Material | n/a | Maximum Operating Pressure | 5000 psi |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Minimum Operating Temperature | -26 °C | Function | 3-Way |
| Override Functionality | n/a | Maximum Inlet Pressure Rating | 350 bar |
| Operation Type | Solenoid Operated | Cavity Size | C10-3 |
| Maximum Operating Temperature | +204 °C | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Valve Material | All parts steel. All operating parts hardened steel | Operating Temperature | -26 to +204 °C |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Mounting Type | Screw in cartridge valve |
| Maximum Flow Rate | 4.5 Gal/min | Configuration | Normally Closed, Normally Open, Selector |
| Input Voltage | 85% of rated voltage at 72°F (20°C) min | Coil Nut Tightening Torque | 7-10 Nm |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Leak Rate | 160 @ 5000 PSI (350 BAR) cm3/min |
| Coil Type | 5/8" Super Coil | Installation Torque | 51-55 lb-ft |
| Weight | 0.42 lb | Flow Rate | 4. 4.5 Gal/min |
| Response Time | 50-100 ms | Seal Material | Fluorocarbon |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Actuation Type | Electrical |
| Configuration | Normally Closed, Normally Open, Selector | Flow Direction | 2-1 De-energized, 3-1 Energized |
| Flow Rate | 4, 4.5 GAL/MIN, 15, 17 L/MIN | | |
