| Actuation Type | Electrical | Seal Material | Nitrile |
| Body Material | n/a | Maximum Operating Pressure | 5000 psi |
| Division | Hydraulic Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Maximum Flow Rate | 3 Gal/min | Function | 3-Way |
| Minimum Operating Temperature | -34 °C | Weight | 0.13 kg |
| Override Functionality | n/a | Maximum Inlet Pressure Rating | 5000 psi |
| Operation Type | Solenoid Operated | Cavity Size | C08-3 |
| Installation Torque | 43-49 Nm | Maximum Operating Temperature | +121 °C |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -34 to +121 °C | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Mounting Type | Screw in cartridge valve | Coil Type | 1/2" Super Coil |
| Configuration | Normally Closed, Normally Open, Selector | Input Voltage | 85% of rated voltage at 72°F (20°C) min |
| Response Time | 50 ms | Coil Nut Tightening Torque | 5-7 lb-ft |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Flow Rate | 7.5, 11.3 L/min |
| Leak Rate | 160 @ 5000 PSI (350 BAR) cm3/min | Seal Material | Nitrile |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Actuation Type | Electrical |
| Configuration | Normally Closed, Normally Open, Selector | Flow Direction | 2-1 De-energized, 3-1 Energized |
| Flow Rate | 2, 3 GAL/MIN, 7.5, 11.3 L/MIN | | |
