Parker DM104LD8 - 4 Way Rotary Type Manual Valve

REGIONAL - Parker’s manually operated 4-way, 2 or 3-position directional control spool valve is capable of flows up to 7.5 lpm (2 gpm) and pressures as high as 240 bar (3500 psi). Knob and lever actuators are available with detents.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. DM104LD8

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Seal Material	Nitrile	Body Material	n/a
Weight	0.3 lb	Division	Hydraulic Systems Division
Installation Torque	22 Nm	Maximum Operating Pressure	240 bar
Maximum Kinematic Viscosity	45-2000 SSU (6 to 420 cSt)	Maximum Inlet Pressure Rating	240 bar
Minimum Operating Temperature	-30 °F	Operation Type	Manual
Cavity Size	C10-4	Maximum Operating Temperature	+250 °F
For Fluid Type	Mineral-based or synthetic hydraulic fluids	Valve Material	All parts steel. All operating parts hardened steel
Operating Temperature	-34 to +121 °C	Filter Efficiency Rating	ISO 4406 18/16/13, SAE Class 4
Function	Spool Type	Flow Rate	7.5 L/min
Leak Rate	164 @ 3500 PSI (240 BAR) cm3/min	Configuration	Lever
Actuation Type	Rotary	Maximum Flow Rate	2 Gal/min
Maximum Tank Pressure	34.5 bar	Detents	2 postion detent
Rotation Angle	90 °	Spool Type	Tandem Center
Seal Material	Nitrile	Configuration	Lever
Detents	2 position detent	Spool Type	Tandem Center
