| Maximum Regulated Flow Rate | 56.8 | Configuration | Normally Closed, Pressure Compensated |
| Current | 2.33 @ 12 VDC, 1.17 @ 24 VDC | Leak Rate | 568 @ 3000 PSI (210 BAR) |
| Installation Torque | 55 | Function | Proportional Flow Control/Regulator |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Cavity Size | C12-4L |
| Operating Temperature | -30 to +250 | Hysteresis | < 15% |
| Coil Nut Tightening Torque | 3 | Body Material | n/a |
| Operation Type | Solenoid operated, Manually opertated | Connection Type | n/a |
| Maximum Operating Temperature | +250 | Override Functionality | Infinite Control |
| Valve Material | All parts steel. All operating parts hardened steel | Flow Rate | 20 |
| Frequency | 100-400 | Minimum Pressure Differential | 200 |
| Division | Hydraulic Systems Division | Minimum Operating Temperature | -30 |
| Seal Material | Nitrile | Weight | 1 |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Variation of Opening Point | N/A |
| Actuation Type | Electrical, Manual | Maximum Flow Rate | 20 |
| Flow Direction | Inlet port 3, Bypass port 2, Regulated port 4 | Connection Size | n/a |
| Power Consumption | 28 | Maximum Inlet Pressure Rating | 3000 |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Flow Rate Accuracy | N/A |
| Maximum Operating Pressure | 3000 | Coil Type | 5/8" Super Coil High Watt (CAP) |
| Flow Rate | 20 GAL/MIN, 75 L/MIN | Seal Material | Nitrile |
| Actuation Type | Electrical, Manual | Configuration | Normally Closed, Pressure Compensated |
