| Operation Type | Solenoid operated, Manually operated | Installation Torque | 55 |
| Maximum Flow Rate | 15.0 | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Minimum Pressure Differential | 300 | Operating Temperature | -30 to +250 |
| Flow Direction | Side to Top (2 - 3) | Valve Material | All parts steel. All operating parts hardened steel |
| Coil Nut Tightening Torque | 3 | Hysteresis | < 15% |
| Override Functionality | Infinite Control | Cavity Size | C12-3L |
| Body Material | n/a | Connection Type | n/a |
| Maximum Operating Temperature | +250 | Weight | 0.89 |
| Minimum Operating Temperature | -30 | Wire Mesh Screen Included | No |
| Current | Max: 2.33 @ 12 VDC, 1.17 @ 24 VDC | Division | Hydraulic Systems Division |
| Seal Material | Nitrile | Actuation Type | Electrical, Manual |
| Frequency | 100-400 | Variation of Opening Point | N/A |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Connection Size | n/a |
| Power Consumption | 28 | Flow Rate Accuracy | N/A |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Maximum Inlet Pressure Rating | 3000 |
| Coil Type | 5/8" Super Coil High Watt (CAP) | Division | Hydraulic Valve Systems Division |
| Maximum Operating Pressure | 3000 | Leak Rate | 568 @ 3000 PSI (210 BAR) |
| Flow Rate | 15 | Function | Proportional Flow Control/Regulator |
| Variation of Closing Point | N/A | Configuration | Normally Closed, Pressure Compensated |
| Seal Material | Nitrile | Actuation Type | Electrical, Manual |
| Configuration | Normally Closed, Pressure Compensated | Flow Rate | 15 GAL/MIN, 56.8 L/MIN |
