| Division | TAIYO Division | Speed Range | 50-500mm/s |
| Pressure Range (MPa) | 0.05-1.0 | Related Parts | Lock nut |
| Cushioning Stroke (mm) | φ40-63:20, φ80-100:25, φ125-150:35 (Cushion ring length) | Rod End Styles | Rod eye(T-end),Rod clevis(Y-end)with pin |
| Bore Diameter (mm) | 40, 50, 63, 80, 100, 125, 150 | Type | With Heavy-duty Scraper Type, Double acting single rod, Standard type |
| Lubrication | Unnecessary Once lubricating the cylinder, you must lubricate it constantly. | Fluid Type | Air |
| Bellows Material | Standard：Nylon tarpaulin Semi-standard：Chloroprene,Conex | Temperature Range (C) | -10-+60(No freezing) |
| Cushioning Type | With cushions on both ends | Stroke Length Tolerance (mm) | 0-250:0-+1.0 251-1000:0-+1.5 1001-1500:0-+2.0 |
| Screw Tolerance | JIS 6g/6H | Proof Pressure (MPa) | 1.5 |
| Mounting Style | SD, LB, FA, FB, CA, CB, TC | | |
