Parker CV-370-MOMS-5 - Modular, High Flow, Hydraulic In Line Check Valves - CV Series

Parker's, in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. CV-370-MOMS-5

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Maximum Operating Pressure	3000 psi	Mounting Type	Threaded
Configuration	n/a	Seat Type	Metal Seal
Connection Size	9/16"-18 UNF inch	Seal Material	Metal
Maximum Operating Temperature	-40 °F	Flow Direction	n/a
Actuation Type	Mechanical	Division	Quick Coupling Division
Minimum Operating Temperature	250 °F	Connection Type	Male ORB to Male Seal-Lok ORFS
Body Material	Steel	Maximum Flow Rate	n/a
Cracking Pressure (psi)	5	Outlet Port Connection Type	Male Seal-Lok
Outlet Port Size (inch)	11/16-16 UN	Inlet Port Connection Type	Male SAE O-ring Straight Thread
Inlet Port Size (inch)	9/16 - 18 UNF	Body Size (inch)	3/8
