*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker CPIFF-12S-5 - Soft Seat, Hydraulic In Line Check Valves - CPIFF Series

Parker's, in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.

AFP Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. CPIFF-12S-5

$102.44/each

Products specifications

Attribute name	Attribute value
UOM	EA	Seat Type	Soft Seat
Minimum Operating Temperature	-15	Body Material	Steel
Maximum Flow Rate	n/a	Maximum Operating Pressure	5000
Actuation Type	Mechanical	Division	Quick Coupling Division
Maximum Operating Temperature	400	Outlet Port Size (inch)	1 1/16 - 12 UN
Body Size (inch)	3/4	Cracking Pressure (psi)	5
Inlet Port Size (inch)	1 1/16 - 12 UN	Outlet Port Connection Type	Female SAE Straight Thread
Seal Material	Fluorocarbon	Inlet Port Connection Type	Female SAE Straight Thread
