Parker BH2-60-STM - General Purpose, ISO 7241-B, Hydraulic Quick Couplings - 60 Series

Name: Parker BH2-60-STM - General Purpose, ISO 7241-B, Hydraulic Quick Couplings - 60 Series
SKU: BH2-60-STM
Price: 68.18 USD
Availability: InStock

Parker's general purpose quick couplers and nipples are versatile for use across a spectrum of applications where fluid, gas or steam lines require fast and easy connection and disconnection.

AFP Availability:

14 In Stock

North Chesterfield, VA

Partner Available:

Quote Required

Quantities sourced from Partner Network may incur an upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

Brand Parker

Part No. BH2-60-STM

$68.18/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Vacuum Pressure Rating	27.4 Inch-Hg
Division	Quick Coupling Division	Valve Type	Poppet
Maximum Operating Temperature	400 °F	Hex Size	0.81 inch
Ball Material	Stainless steel	Body Material	Brass
Minimum Operating Temperature	-65 °F	Plating Type	na
Product Type	Manual Connect	Specifications Met	ISO 7241-1, series B
Flow Rate	3 Gal/min	Valve Material	Brass
Application	Steam	Maximum Operating Pressure	3700
Coupling Half	Female Coupler	Connection Thread Size (inch)	1/4 - 18
Body Size (inch)	1/4	Seal Material	Ethylene Propylene
Body Material	BRASS	Connection Type	Female NPTF
