Parker B6X2000XXA - B Series Single Air Piloted 3-way 2-position Valve

B Series Single Air Piloted 3-way 2-position Valve

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. B6X2000XXA

$51.08

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
UOM	EA	Operator Type Detail	Single
UOM	EA	Port	1/4 NPT
Offset Return Type	Air Return	CV Factor	1.4
Pkg Qty	1	Offset Return Type	Air Return
Operating Temperature	-15°C to 49°C (5°F to 120°F)	Valve Positions	2-position
Operator Type	Air Piloted	Valve Passages	3-way
Port	1/4 NPT	Operator Type Detail	Single
Parker Group	Automation	Parker Division	Pneumatic
Pneumatic Valve Type	Inline Valve	Port Inch/BSP	NPT
Supply Pressure Range	20 to 145 PSIG (1.4 to 10 bar)	CV Factor	1.4
Series	B
