*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker 961-711112-000 - Series MX - Miniature Solenoid Actuated Poppet Valve

MX 10 mm miniature valve is designed to deliver high flow at low pressure for portable medical devices with limited space and power.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 961-711112-000

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Maximum Operating Pressure	0.4 bar	Length	38.1 mm
Maximum Operating Temperature	122 °F	Body Material	PPE/PA
For Fluid Type	Gases	Out of Stock Lead Time	10
Control Method	Current or Voltage	Maximum Flow Rate	18 SLPM
Cycles per Lifetime	up to 25 Million	Seal Material	Silicone
Connection Type	Barb for 3/32" (2 mm) I.D. Tubing	Weight	0.3 oz
Input Voltage	5 VDC	Division	Precision Fluidics Division
Power Consumption	0.25 W	Height	15.7 mm
Configuration	n/a	Actuation Type	Solenoid
Minimum Operating Temperature	41 °F	Orifice Size	1.91 mm
Flow Rate	up to 18 SLPM	Electrical Connection	2 Pin - Up
Response Time	< 20 ms Max Cycling	Leak Rate	< 0.2 cm3/min
Width	10.1 mm	Mounting Type	Manifold (Gasket Required)
Operation Type	Electronic	Max Order Quantity	9
Industry Application	Negative Pressure Wound Therapy	Standard Lead Time	20
Connection Size	2-56 x 1/2" Pan Head Phillips Screw	Shipping Weight	0.22
Function	2-Way	Electrical Connection	2 Pin-Up
Elastomer	Silicone	Maximum Operating Voltage	5 VDC
Application Pressure Requirement	6 psi	Type/Configuration	2-Way NC
