Parker 8MP7-MAB4LPK-V-SSP - Ball Valve, 15,000 PSI - MAB Series

Parker’s MAB Series MPI Ball Valves are available as manual, pneumatic and electrical actuated two-way and three-way valves. They are designed for 1/4 and 1/2 turn media shutoff or switching applications up to 15,000 psi.

Availability:	Quote Required
Partner Available:	Quote Required

Brand Parker

Part No. 8MP7-MAB4LPK-V-SSP

Ship to

Shipping Method

Estimated Delivery

Price

No shipping options

Products specifications

Attribute name	Attribute value
Connection 2 Size	MPI Compression	Seal Material	Fluorocarbon Rubber
Division	Instrumentation Products Division	Valve Type	n/a
Body Material	Stainless Steel 316	Orifice Size	0.25 inch
Seat Material	PEEK	Connection 3 Thread Size	n/a
Valve Configuration	2-Way	Connection 1 Size	MPI Compression
Connection 3 Size	N/A	Maximum Operating Pressure	15000 psi
Options	n/a	Connection 1 Size	1/2"
Connection 2 Style	MPI Compression Fitting	Valve Type	N/A
Connection 2 Size	1/2"	Connection 3 Thread Size (inch)	N/A
Orifice Size	0.25	Options	n/a
Seat Material	PEEK	Seal Material	Fluorocarbon Rubber
Maximum Working Pressure (psi)	15,000	Connection 1 Style	MPI Compression Fitting
Valve Configuration Type	Two Way	Connection 3 Style	N/A
Body Material	316 Stainless Steel
